Dimensions & weight

Weight

8.7 kg; weight in size M, standard specification and without pedals

Permissible system weight

135 kg

Frame size XS

Size in mm: 480; seat tube: 425 mm; top tube: 511 mm; head tube: 100 mm; head angle: 70.5°; seat angle: 74.5°; chainstay: 425 mm; bottom bracket drop: 75 mm; fork length: 425 mm; fork offset: 53 mm; wheelbase: 1016 mm; stack: 546 mm; reach: 375 mm; standover height: 770 mm; effective: 432 mm; effective stack: 616 mm

Frame size S

Size in mm: 510; seat tube: 455 mm; top tube: 535 mm; head tube: 110 mm; head angle: 71°; seat angle: 74°; chainstay: 425 mm; bottom bracket drop: 75 mm; fork length: 425 mm; fork offset: 53 mm; wheelbase: 1030 mm; stack: 557 mm; reach: 390 mm; standover height: 789 mm; effective: 447 mm; effective stack: 626 mm

Frame size M

Size in mm: 540; seat tube: 485 mm; top tube: 550 mm; head tube: 130 mm; head angle: 71°; seat angle: 73.5°; chainstay: 425 mm; bottom bracket drop: 75 mm; fork length: 425 mm; fork offset: 53 mm; wheelbase: 1041 mm; stack: 576 mm; reach: 395 mm; standover height: 813 mm; effective: 462 mm; effective stack: 646 mm

Frame size L

Size in mm: 570; seat tube: 515 mm; top tube: 566 mm; head tube: 150 mm; head angle: 71°; seat angle: 73.5°; chainstay: 425 mm; bottom bracket drop: 75 mm; fork length: 425 mm; fork offset: 53 mm; wheelbase: 1058 mm; stack: 595 mm; reach: 405 mm; standover height: 836 mm; effective: 482 mm; effective stack: 665 mm

Frame size XL

Size in mm: 600; seat tube: 545 mm; top tube: 596 mm; head tube: 180 mm; head angle: 71°; seat angle: 73°; chainstay: 425 mm; bottom bracket drop: 75 mm; fork length: 425 mm; fork offset: 53 mm; wheelbase: 1083 mm; stack: 623 mm; reach: 420 mm; standover height: 863 mm; effective: 497 mm; effective stack: 693 mm

Compatibility

Bottom bracket

Sram, BSA DUB; 68 mm BSA

Headset

ACROS IS52 / IS52 (ICR), FOCUS C.I.S. Integrated; headset standard IS52 with ACROS AIF-540R1 ICR IPS

Wheel size

Designed for 28-inch or 700c wheels only; not 650B compatible

Maximum tyre clearance

Fork: 53 mm; rear wheel: 45 mm for the 8. series

Groupset compatibility

All standard Shimano and SRAM groupsets with the specified chainlines and crankset sizes

Smart trainer compatibility

Yes

Front rack compatibility

A front rack can be attached to the bonded alloy thread insert on top of the fork

Fender compatibility

Fenders can be added to the 6. and 8. series

Dropper post compatibility

An internal dropper post can technically be added

Water bottle cage mounts

Three water bottle cages: one on the seat tube, one on top of the down tube and one underneath the down tube

Sizing

Available sizes

XS, S, M, L, XL

Handlebar width by size

XS: 400 mm; S: 400 mm; M: 400 mm; L: 420 mm; XL: 440 mm

Stem length by size

XS: 80 mm; S: 80 mm; M: 90 mm; L: 100 mm; XL: 100 mm

Crank length by size

XS: 165 mm; S: 170 mm; M: 172.5 mm; L: 172.5 mm; XL: 175 mm

Seatpost length by size

XS: 350 mm; S: 350 mm; M: 350 mm; L: 350 mm; XL: 400 mm

Features

Special features

Prep Pocket & Prep Pack

Shifter

SRAM Rival E1

Rear derailleur

SRAM Rival E1 XPLR AXS, 13-speed

Cassette

SRAM XG-1351 XPLR, 10-46T

Chain

SRAM Rival E1

Crankset

SRAM Rival E1, 40 T

Brakes

SRAM Rival E1 front and rear

Disc brake rotors

SRAM HS2; front: 180 mm for sizes L-XL and 160 mm for sizes XS-M; rear: 160 mm

Headset

ACROS IS52 / IS52 (ICR), FOCUS C.I.S. Integrated

Saddle

fi'zi:k Ridon X5

Tyres

Schwalbe G-One R Pro, super race, tubeless ready, 45-622 front and rear

What's included

Prep Pack

Included in the Prep Pocket

Accessory kit

Includes a 4 mm Allen key bit for the seatpost clamp and a frame protection sticker kit
